Summary
This Technical Brochure presents the principal design of HVDC meshed grid protection and local control systems. It describes the requirement on HVDC grid protection and control, system earthing schemes, short circuit phenomena, short circuit interruption and short circuit limiting methods, protection philosophies and functions. The guide includes the possible measurement methods and protection functions for HVDC grid protections including fault location methods to minimise the repair time after a short circuit occurrence.
Additional informations
| Publication type | Technical Brochures |
|---|---|
| Reference | 739 |
| Publication year | |
| Publisher | CIGRE |
| Study committees |
|
| Working groups | JWG B4/B5.59 |
| File size | 5 MB |
| Pages number | 96 |
| Price for non member | 180 € |
| Price for member | Free |
Authors
JIN, Urganov
Keywords
